UMEGINE — DirectX 11 3D Game Engine

A custom 3D game engine built from scratch using C++20 and DirectX 11. This project demonstrates practical understanding of low-level graphics API, engine architecture patterns, and modern C++ development practices.

This is a learning-focused project aimed at understanding the internals of game engine development, not a production-ready engine.

🎯 Current Features

Graphics & Rendering

• DirectX 11 Renderer: Custom abstraction layer (RHI) over D3D11 API
• Lighting System:
  • Directional lights with configurable intensity and color
  • Point lights with distance-based attenuation (up to 16 lights per scene)
  • Shadow mapping for directional lights with PCF (Percentage Closer Filtering)
• PBR Material System:
  • Cook-Torrance GGX BRDF (metallic workflow)
  • Per-pixel metallic/roughness textures from glTF
  • Normal mapping support
  • Ambient occlusion maps with configurable strength
  • Emissive maps with emissive factor
  • Alpha blending (two-pass: opaque front-to-back, transparent back-to-front)
  • Alpha cutout rendering for foliage/vegetation
• Environment Rendering:
  • Skybox rendering with HDR cubemap support
  • Image-Based Lighting (IBL) with split-sum approximation (irradiance + prefiltered radiance)
  • Analytical EnvBRDF approximation (no LUT texture needed)
• Post-Processing:
  • Offscreen HDR render target (R16G16B16A16_FLOAT)
  • Reinhard tone mapping (luminance-based)
  • Fullscreen quad pass to backbuffer
• Asset Loading:
  • glTF 2.0 model loading via tinygltf
  • DDS texture loading via DirectXTex
  • Automatic tangent generation for normal maps

Editor

• ImGui-based editor integrated through RHI abstraction (API-agnostic)
• Scene Hierarchy panel with entity list from ECS registry
• Inspector panel with real-time transform editing (DragFloat3 for position)
• Game/Editor mode toggle (Insert key) with cursor lock/unlock
• Input separation: editor and game input are fully isolated when editor is active

Architecture

• RHI (Rendering Hardware Interface): Abstraction layer separating engine logic from DirectX 11 specifics
• ECS (Entity-Component-System): Using EnTT for data-oriented design and entity management
• Scene Graph: Parent-child transform hierarchies with cached world matrices
• Resource Management: Centralized resource manager with asset caching
• Virtual File System: Custom VFS for asset path resolution

Core Systems

• Event System: Observer pattern for engine-wide event handling (window resize, input, etc.)
• Input Management: Keyboard and mouse input abstraction
• Logging: Custom logger with severity levels
• High-Precision Timer: Delta time calculation for frame-independent logic

🛠 Tech Stack

• Language: C++20
• Graphics API: DirectX 11 (D3D11), HLSL Shader Model 5.0
• Build System: CMake 3.20+
• Dependencies:
  • EnTT: Entity-Component-System library
  • tinygltf: glTF 2.0 model loader
  • DirectXTex: Texture loading and DDS format support
  • DirectXMath: SIMD-optimized math library
  • SDL3: Window and input handling
  • Dear ImGui: Editor UI (with SDL3 + DX11 backends)
  • nlohmann_json: JSON parsing

📁 Project Structure

UMEGINE/
├── UMEGINE/              # Core engine library
│   └── Source/
│       ├── RHI/          # Rendering Hardware Interface (D3D11 abstraction)
│       ├── Graphics/     # High-level rendering (Renderer, Camera, Materials, Mesh)
│       ├── Scene/        # ECS components and scene management
│       ├── Core/         # Engine core (events, logging, filesystem, time)
│       ├── Editor/       # ImGui-based editor (hierarchy, inspector)
│       ├── Resources/    # Asset management
│       └── Utils/        # Math utilities (DirectXMath wrappers)
└── Elysia/               # Sandbox application for testing
    └── Resources/        # Shaders (HLSL) and test assets

🚧 Known Limitations

• Frustum culling is basic (AABB-based)
• No level-of-detail (LOD) system
• No occlusion culling
• Single-threaded rendering
• No deferred rendering
• Limited to DirectX 11 (no Vulkan/Metal support)
• Shadow mapping limited to single directional light (no cascades)

🎓 Learning Goals

This project serves as a deep dive into:

• Low-level graphics API usage (resource management, pipeline state, shader compilation)
• Modern engine architecture patterns (ECS, RHI abstraction, component-based design)
• HLSL shader programming (vertex/pixel shaders, constant buffers, shadow mapping)
• C++20 features and best practices
• Build system configuration (CMake, vcpkg)
